L76K GNSS Module for SeeedStudio XIAO is a Multi-GNSS (Global Navigation Satellite System) module compatible with all XIAO development boards, supports GPS, BeiDou (BDS), GLONASS and QZSS systems, allows multi-system combined or single-system independent positioning. It also supports AGNSS function, built-in low-noise amplifier and sound surface filter, and provides a good positioning experience of fast, accurate, high-performance.

The module comes with a high-performance active GNSS antenna intended to cover GPS L1 C/A, BeiDou B1 and GLONASS L1 bands. The design also has a tiny bright green LED for indicating the 1PPS output on a fix.

Applications:
GPS navigation
GPS Tracker
Smart City
Logistics and Freight Management
Item Detail
GNSS bands GPS L1 C/A: 1575.42MHz
GLONASS L1: 1602MHz
BeiDou B1: 1561.098MHz
Channels 32 tracking ch/72 acquisition ch
TTFF (Time To First Fix) Cold Starts: 30s(w/o AGNSS), 5.5s(w/ GNSS)
Hot Starts: 5.5s(w/o AGNSS), 2s(w/ AGNSS)
Sensitivity Auto-acquisition: -148dBm
Tracking: -162dBm
Re-acquisition: -160dBm
Accuracy Position: 2.0m CEP
Velocity: 0.1m/s
Acceleration: 0.1m/s²
Timing: 30ns
UART Interface Baud Rate: 9600~115200bps(9600bps default)
Update Rate: 1Hz(default), 5Hz(Max.)
Protocol: NMEA 0183, CASIC proprietary protocol
Antenna Type: Active Antenna
Operating Frequency: 1559–1606MHz
Coaxial Cable: RF1.13 Length=10cm
Cable Connector: U.FL Plug RA
Current consumption(w/ active antenna) Auto-acquisition: 41mA
Tracking: 41mA
Standby: 360uA
Dimension 18mm x 21mm

Features:

Enhanced Reception: Built-in Low Noise Amplifier and Surface Acoustic Wave Filter for improved sensitivity and noise reduction
High Precision: 32/72 channels, -162dBm tracking, -160dBm re-acquisition sensitivity
Energy Efficiency: 41mA tracking/acquisition, 360µA standby
Multi-GNSS Systems: Powered by Quectel L76K, supporting GPS, BeiDou, GLONASS and QZSS
Ceramic Antenna: Enhanced signal reception, superior to traditional antennas.

Package Includes:

1× L76K GNSS Module
1× Active Antenna with iPex connector
2× 7 Pin Female Header 2.54mm
