geo-FENNEL GFN 10, 360° (32x) Precision Automatic Level

Product Overview

• Robust all-metal housing.
• Carrying handle for easy handling.
• 32x telescope magnification with a large diameter objective lens for optimum resolution.
• Available as a set with tripod and levelling staff (optional).

Features

• Robust metal housing with
  handle for comfortable handling
• Reticle in wedge-shape for most
  accurate reading
• Well protected internal circle
• Compensator test button
• Bubble reading mirror

Specifications

• Mean error for 1 km double levelling: ± 1,0 mm
• Telescope magnification: 32 x
• Objective diameter: 40 mm
• Shortest focussing distance: 0,6 m
• Working range of compensator: ± 15'
• Levelling accuracy: ± 0,3"
• Circular bubble: 8' / 2 mm
• Horizontal circle: 400 gon / 360°
• Dust / water protection: IP 65
• Weight (instrument only): 1,6 kg
